Description:
The Bendix Tractor Protection Valve part # BW065706 TP-3DC is a genuine OEM component that safeguards tractor-trailer braking systems. Engineered for durability, it prevents air loss and ensures consistent brake function by managing supply and control lines. Designed for harsh operating conditions, it delivers reliable performance and long service life for fleet vehicles.
Features:
OEM Part#: BW 065706
Model: TP-3DC
Mounting Type: Cab/Chassis
Mounting Location: Cab/Chassis
Vented: Yes
Trailer Service Port Thread Size: 1/2-14 NPT in
Tractor Protection Port Thread Size: 1/4-18 NPT in
Trailer Supply Port Thread Size: 1/2-14 NPT in
Auxiliary Supply Port Thread Size: 1/4-18 NPT in
Tractor Primary Control Port Thread Size: 3/8-18 NPT in
Stop Light Switch Port Thread Size: 1/4-18 NPT in
Tractor Secondary Control Port Thread Size: 3/8-18 NPT in
Supply Port Thread Size: 1/4 PT in
Control Port Thread Size: 3/8 PT in
Service Line Shut Off Pressure: 20 psi
Operating Temp: -40°F to 200°F
Length: 171.70 mm
Width: 55.63 mm
Height: 82.80 mm
Mounting Dimension: 0.34 in
- BW 065706
