Description:
Bendix BW part # 800529 Universal Parking Brake Valve delivers precise regulation of air pressure for tractors and trailers. Featuring MV-3 dash control, dual delivery ports, and user-friendly buttons, it ensures safe and reliable operation for heavy-duty commercial trucks.
Features:
OEM Part#: BW 800529
Vehicle: Universal / Heavy-duty trucks
Type: MV-3 Dash Control Valve
Delivery 21 Port Thread Size: 1/4-18 NPT in
Delivery 22 Port Thread Size: 1/4-18 NPT in
Supply 11 Port Thread Size: 1/4-18 NPT in
Supply 12 Port Thread Size: 1/4-18 NPT in
Delivery Port Quantity: 2
Number Of Delivery Port: 2
Buttons Included: Yes
Tractor Trip Pressure: 20 to 40 psi
Trailer Trip Pressure: 25 to 45 psi
Trailer Override Pressure: 20 to 30 psi
Minimum Operating Temperature: -40°F
Maximum Operating Temperature: 200°F
Length: 128.52 mm
Width: 209.30 mm
Height: 78.99 mm
Mounting Dimension: 0.20 in
Exhaust Port Thread Size: 1/4-18 NPT in
Buttons Included: Yes
Brand: Bendix
OEM Cross Reference: 800529BXW, 800529BXR, BW800529, BX800529, BEN-800529, 5000815, 5000819, 5005068, 5005086, 800087, 745-800529 / 745800529, A12-17319-006, A12-17319-011, 1217319006 / 1217319011, BAN800529, ZAC800529, PD800529
